The C Series Jaw Crusher is primarily used for medium crushing of various ores and bulk materials, commonly employed in industries such as mining, metallurgy, construction materials, highways, railways, water conservancy, and chemical engineering. It is suitable for coarse and medium crushing operations. This series integrates advanced crushing technology and production processes, offering advantages in structural design, performance, service life, and equipment maintenance, making it a key choice for efficiently crushing hard and corrosive materials.
The C Series high-performance jaw crusher features a new tooth-shaped protective plate, which enhances production and extends the maintenance cycle of wear parts.
It employs the V-shaped crushing chamber, currently the most popular design globally, ensuring stable performance.
The overall cast steel bearing seat perfectly matches the frame, significantly enhancing the radial strength of the bearing seat and reducing maintenance costs.
| Model | Feeder Opening Size(mm) | Max. Feeding Size(mm) | Outlet adjusting range(mm) | Eccentric shaft speed(mm) | capacity(t/h) | Motor Power(kw) |
| Stationary type application | ||||||
| C80 | 500×750 | 400 | 40-150 | 290 | 50-160 | 55-75 |
| C90 | 610×910 | 500 | 60-180 | 260 | 60-180 | 90 |
| C100 | 760×1060 | 600 | 70-200 | 260 | 150-300 | 132 |
| C110 | 850×1100 | 700 | 70-200 | 230 | 200-400 | 132-160 |
| C125 | 950×1250 | 800 | 100-250 | 220 | 300-800 | 160 |
| C140 | 1070×1400 | 900 | 125-270 | 220 | 400-900 | 200 |
| C160 | 1200×1600 | 1000 | 150-300 | 220 | 500-1200 | 250 |
| C200 | 1500×2000 | 1200 | 175-300 | 200 | 800-1400 | 400 |
| Mobile type application | ||||||
| C96 | 580×930 | 480 | 60-170 | 290 | 60-160 | 90 |
| C106 | 700×1060 | 580 | 70-180 | 280 | 150-300 | 110 |
| C116 | 760×1150 | 680 | 70-190 | 260 | 200-400 | 132 |
| C120 | 870×1200 | 780 | 70-200 | 230 | 400-500 | 160 |
